SS Frit Feature
1. SS frit is made from stainless steel powder particle
2. SS frit is sintered in a high temperature vacuum furnace. So stainless steel powder particle won’t shed
3. SS frit is a good filter media for surface filtration and depth filtration
4. SS frit has narrow pore size distribution
5. High dirt holding capacity
6. Good porosity
7. High filter rating accuracy
8. The effect of filtration is good
9. High filter efficiency
10. Good permeability
11. Pressure loss is low in filtration process
12. High flow rate at low differential pressure
13. High compression strength
14. Good mechanical strength
15. Good abrasion resistance
16. Good durability against most liquids, gases and aggressive steam
17. High temperature resistance
18. High corrosion resistance
20. Washable and Cleanable
22. Long service life
23. Easy to be welded, fabricated
SS Frit Technical Data
Raw Material: SS 316L
Filter Rating: 0.22-100 Microns
Operation Temperature: ≤ 816 ℃
Diameter: ≤ 400 mm
Thickness: 1 mm,1.5 mm,2 mm,3 mm,5 mm or others
Solvent filters for chromatography systems.
Polymer filters for processing molten plastic materials.
Catalyst recovery filters in petrochemical plants and food and beverage applications.
Gas filters for chemical processing and semiconductor manufacturing applications.
Sensor covers to protect delicate instruments in harsh environments (such as smoke stacks and exhaust pipes).
2. Flow Control Devices, Breathers, and Pressure Equalizers
Small fitting-mounted flow restrictors that replace expensive micro valves and orifice devices used in gas leak detectors in the mining industry or in other analytical equipment.
Vent plugs that allow internal pressure of systems to come to equilibrium with outer atmospheres such as in space vehicles, automotive (truck and train) brake systems, and instrument cabinets used in harsh environments.
Vacuum delay valves in automotive carburetors.
Pump priming vents for pharmaceutical micropumps.
3. Flame Arrestors
Gas detectors for mining operations.
Oxygen sensor covers in turbine and jet engine inlet cones.
Protective covers for electronic process sensors.
Carbonation of beverages.
Addition of CO2 to neutralize acidic waste stream in paper processing.
Aeration of sewage effluent to increase biological activity.
Addition of air into fermentation processes such as beer brewing or fuel ethanol production.
Introducing hydrogen into refinery cracking operations.
Increasing the oxygen content in fish farming plants.
Adding ozone to a water treatment stream.
Introducing nitrogen into food products such as beverages and cooking oils to remove oxygen and extend shelf life.
5. Rollers and Applicators
Finish coatings for printing papers.
Solvent-based adhesive coating of tapes.
Ink jet printer plates.
Air rollers for handling sensitive films with no direct surface-to-surface contact.
Fluidizing cones on silo outlets to aid dry process chemical flow into a reactor.
Moving dry goods, such as cereals, through process tubing.
Loosening of bulk dry chemicals after transport prior to dumping.
7. Gauge Snubbers
Vehicle or train air brakes.
Gas-activated process valves in chemical plants.
Air and vacuum pump discharge mufflers.
